Medical Oxygen Cylinder Regulator With Flowmeter And Humidifier/Oxygen Flowmeter (China) Japan Technology

Product Identification:

# Product Name: Oxygen Flowmeter
# Origin: China
# Technology/Marketing Description: Japan Technology

Features:

• Adjustable oxygen-flow delivery up to 15 LPM

• Clear vertical flow scale

• Integrated cylinder-pressure gauge

• Reusable humidifier bottle

• Humidifier water-level markings

• Durable chrome-plated metal construction

• Compact cylinder-mounted design

• Hand-tight cylinder connection

• Fine flow adjustment using the control knob

• Suitable for humidified oxygen delivery

• Easy connection to standard oxygen tubing

• Designed for medical and emergency oxygen applications

Technical Specifications:

* Gas Type: Medical Oxygen

* Regulator Structure: Single-stage pressure-reducing type

* Flow Range Shown: 1–15 LPM

* Commonly Quoted Flow Range: 0–15 LPM

* Flow Adjustment: Adjustable by manual flow-control knob

* Flow Indication: Floating metal ball inside a transparent vertical flow tube

* Pressure Gauge Range Shown: Approximately 0–4,000 psi / 0–280 kgf/cm²

* Typical Maximum Inlet Pressure: Approximately 3,000 psi

* Typical Regulated Outlet Pressure: Approximately 0.2–0.3 MPa / 2–3 bar

* Typical Safety-Valve Pressure: Approximately 3.5 ± 0.5 bar

* Regulator Body Material: Metal or brass construction with chrome-plated finish

* Flowmeter Tube Material: Transparent impact-resistant plastic, commonly polycarbonate or acrylic

* Flowmeter Scale: Clearly graduated vertical scale

* Humidifier Type: Reusable, non-heated bubble humidifier

* Humidifier Water: Distilled water only

* Humidifier Capacity: To be confirmed by the supplier

* Patient Outlet: Barbed connector for standard oxygen tubing

* Cylinder Connection: Top-entry, hand-tight threaded connection

* Exact Inlet Thread: To be confirmed according to the oxygen-cylinder valve

* Product Colour: Green, chrome/silver, white and transparent

* Installation Position: Vertical/upright

* Operating Medium: Clean and dry medical oxygen

Common Applications:

# Hospitals and nursing wards

# Clinics and medical centres

# Emergency rooms

# Ambulances and patient-transport vehicles

# Home oxygen therapy under medical supervision

# Oxygen delivery through nasal cannulas

# Simple oxygen masks and non-rebreather masks

# Humidified low-flow oxygen therapy

Package Includes:

# 1Set×Oxygen Flowmeter And Humidifier In Hard Box
